Front Door Speaker Removal Note

WARNING: This page is about a different car, the 2009 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.

Remove the front door speaker in the direction of the arrow shown in the figure.
With Bose®

Fig 1: Identifying Front Door Speaker Bolts (With Bose®)
Courtesy of MAZDA MOTORS CORP.

Without Bose®

Fig 2: Identifying Front Door Speaker Bolts (Without Bose®)
Courtesy of MAZDA MOTORS CORP.
