Squeak/Screech Noise or Vertical Scratches in the Window Glass - Adjusting the Weatherstrip Flange

Squeak/Screech Noise or Vertical Scratches in the Window Glass - Adjusting the Weatherstrip Flange

1. Fully lower the affected window.

2. Remove the exterior door glass weatherstrip. For additional information, see - Front Door - Exploded Viewor - Rear Door - Exploded View.

3. Fully raise the window.

4. Measure the distance from the inside edge of the weatherstrip flange to the outside surface of the glass.

- The distance should be greater than 6 mm (0.24 in) and less than 10 mm (0.39 in).





5. If the distance between the inside edge of the weatherstrip flange to the outside surface of the glass is out of specification, use a suitable tool to evenly bend the flange into specification.

6. Fully lower the window.

7. Thoroughly clean the door glass weatherstrip with soapy water and reinstall.
