Front Engine Block

WARNING: This page is about a different car, the 2007 Mazda B2300. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Disassembling View Of Front Engine Block
G04929267Courtesy of MAZDA MOTORS CORP.
