Camshaft Oil Clearance Inspection

CAMSHAFT JOURNAL - CLEARANCE, PLASTIGAGE METHOD

Note: The camshaft journals must meet specifications before checking camshaft journal clearance.





1. Remove the camshaft bearing cap and lay Plastigage across the surface.

Note: Do not turn the camshaft while carrying out this procedure.

2. Position the camshaft bearing cap and install the bolts.
3. Use Plastigage to verify the camshaft journal clearance.
^ If it is out of specification, install new components as necessary.
