Crankshaft Rear Oil Seal Removal / Installation - 4.0L: Removal

  1. Remove the flexplate or flywheel. See FLEXPLATE REMOVAL / INSTALLATION - 4.0L  .
  2. Remove the crankshaft spacer plate.
  3. Remove the crankshaft spacer.
    CAUTION:
    • Avoid scratching or damaging the oil crankshaft seal running surface during removal of the crankshaft rear oil seal.
    Fig 1: Removing Crankshaft Rear Oil Seal
    G04307508Courtesy of MAZDA MOTORS CORP.
  4. Using the seal remover SST  , remove the crankshaft rear oil seal.
