Clutch Release Cylinder Removal/Installation

WARNING: This page is about a different car, the 2003 Mazda Protege5, 2003 Mazda Protege, 2002 Mazda Protege5, and 2002 Mazda Protege. However, it is still accessible from the selected car via links, so may be relevant.

CAUTION:

Clutch fluid will damage painted surfaces. If clutch fluid does get on a painted surface, wipe it off immediately.

Remove in the order indicated in the table.
Plug the clutch pipe after removing it to avoid leakage.

Fig 1: Removing Master Cylinder - FS Engine
Courtesy of MAZDA MOTORS CORP.

Fig 2: Removing Master Cylinder - ZM Engine
Courtesy of MAZDA MOTORS CORP.
Install in the reverse order of removal.
