Camshaft Oil Seal: Removal

WARNING: This page is about a different variant/trim than selected.
  1. Remove the camshaft timing sprockets. Refer to TIMING DRIVE COMPONENTS - TIMING SPROCKETS .
    2. NOTE: The exhaust camshaft oil seal is shown, the intake camshaft oil seal is similar.
    Fig 1: Removing Camshaft Oil Seals
    G02170709Courtesy of MAZDA MOTORS CORP.
  2. Using the special tool, remove the camshaft oil seals.
