WARNING: This page is about a different car, the 2002 Ford Escape, 2001 Mazda Tribute, and 2001 Ford Escape. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Powertrain Control Module Harness Connector Terminals
