Rear A/C System
WARNING: This page is about a different car, the 2002 Mazda MPV. However, it is still accessible from the selected car via links, so may be relevant.
Rear A/C unit is located aft of right rear wheelwell, and contains an evaporator, heater core blower motor, blower relay and blower motor resistor. To operate rear A/C-heater unit, front A/C on-off switch is in ON position and rear main A/C switch is in any position except off. Rear A/C switch will not function unless rear main A/C switch is on. See Fig 1 .
