Upper Intake Manifold: Installation
WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2001 Mazda Tribute, 2001 Mazda Protege, 2001 Mazda Millenia, 2001 Mazda MX-5 Miata, and 2001 Mazda MPV. However, it is still accessible from the selected car via links, so may be relevant.
Inspect intake manifold gasket and replace if necessary. Install intake manifold and 5 mounting bolts. Tighten bolts evenly to specification. See TORQUE SPECIFICATIONS . To complete installation, reverse removal procedure.
Tighten upper intake manifold bolts evenly in sequence in 2 passes. See Fig 1. Tighten to specification. See TORQUE SPECIFICATIONS . To complete installation, reverse removal procedure.
Reinstall upper intake manifold using NEW gasket. Tighten upper intake manifold bolts evenly in crisscross pattern in 2 passes. Tighten to specification. See TORQUE SPECIFICATIONS . To complete installation, reverse removal procedure.
