Hydraulic Lash Adjuster (HLA) Removal/Installation: Notes

WARNING: This page is about a different car, the 2003 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the timing chain. (See TIMING CHAIN REMOVAL/INSTALLATION .)
  2. Remove in the order indicated in Fig 1.
    Fig 1: Removing Hydraulic Lash Adjuster
    G01929690Courtesy of MAZDA MOTORS CORP.
  3. Install in the reverse order of removal.
