Windshield Washer Nozzle Adjustment

WARNING: This page is about a different car, the 2004 Mazda RX-8. However, it is still accessible from the selected car via links, so may be relevant.
  1. Insert a needle or an equivalent tool into the spray hole of the windshield washer nozzle, and adjust the nozzle direction. See Fig 1 .
    Fig 1: Adjusting Windshield Washer Nozzle
    G01344639Courtesy of MAZDA MOTORS CORP.
