DTC P0763: Shift Solenoid C Circuit Malfunction (Open Circuit/Short Circuit): Notes

WARNING: This page is about a different car, the 2004 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Possible Causes - DTC P0763
G01027860Courtesy of MAZDA MOTORS CORP.
