Trunk Side Trim Removal/Installation

WARNING: This page is about a different car, the 2004 Mazda RX-8. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the trunk end trim. See TRUNK END TRIM REMOVAL/INSTALLATION .
  2. Remove the fasteners, then remove the trunk side trim.
    Fig 1: Removing/Installing Trunk Side Trim
    G00379532Courtesy of MAZDA MOTORS CORP.
  3. Install in the reverse order of removal.
