Disassembly (FA4A-EL)

  1. Remove snap rings and stopper plugs. See Figure . Remove accumulator pistons by applying air pressure to oil passages. See Figure .
  2. Measure spring free length. See FA4A-EL ACCUMULATOR SPRING SPECIFICATIONS  table. If not within specifications, replace spring.
