Power Steering Pump

Loosen bolts and nut and adjust belt deflection by turning adjusting bolt. See Fig 1, Figure and Figure . See ADJUSTMENT SPECIFICATIONS . Tighten bolts to specification. See TORQUE SPECIFICATIONS .

Fig 1: Adjusting Power Steering Pump Belt (1.6L)
G00160460Courtesy of MAZDA MOTORS CORP.
