Removal & Installation (B2200 & B2600i)

Remove steering wheel and column covers. Remove screws and instrument cluster cover. See Fig 1 . Remove instrument cluster mounting screws. Disconnect harness connector and speedometer cable. Remove instrument cluster. To install, reverse removal procedure.

Fig 1: Removing Instrument Cluster (B2200 & B2600i)
G90J01278Courtesy of MAZDA MOTORS CORP.
WARNING: Miata is equipped with air bag restraint system. See AIR BAG RESTRAINT SYSTEM article for warnings and safety precautions.
