Power Steering Pump

Loosen power steering pump bolt and nut, and adjust belt deflection by turning adjusting bolt. See Fig 1, Figure and Figure . See ADJUSTMENT SPECIFICATIONS . Tighten bolts to specification. See TORQUE SPECIFICATIONS .

Fig 1: Adjusting Power Steering Pump Belt
G00160477Courtesy of MAZDA MOTORS CORP.
