1994 Miata

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 1994 Mazda MX-5 Miata, 1992 Mazda MX-5 Miata, 1992 Mazda MPV, 1992 Mazda B2200, and 1991 Mazda MX-5 Miata. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect negative battery cable. Remove gear selector console cover. Disconnect Hold switch connector.
  2. Place gear selector in Park. Turn ignition on. Check terminal voltages and continuity. See Figure .
  3. Disconnect shift-lock actuator connector to check continuity between terminal "C" harness side and ground. If not as specified, repair wiring harness and/or replace shift-lock actuator.
