4th Gear Position
WARNING: This page is about a different variant/trim than selected.
| Item | Description |
|---|---|
| 1 | Held components |
| 2 | Driven components |
| 3 | B (4, 6, R) clutch |
| 4 | A (1, 2, 3, 4, 5) clutch |
- In fourth gear, the A (1, 2, 3, 4, 5) clutch holds the output sun gear stationary.
- The B (4, 6, R) clutch holds the reaction sun gear at turbine shaft speed.
- The turbine shaft and input sun rotate.
- The input ring rotates.
- The input carrier and output ring rotate.
- The output carrier rotates at a 1.84:1 ratio.
