3.0L EcoBoost

WARNING: This page is about a different variant/trim than selected.
GFD377231Courtesy of FORD MOTOR COMPANY
Item Description
1 Fuel injectors
2 Fuel rails
3 High-pressure fuel pump
4 High-pressure fuel pump drive unit
5 Throttle Body
