Connector End View (C4218) - REAR WINDOW WIPER MOTOR
WARNING: This page is about a different car, the 2018 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.
Connector: C4218
Description
REAR WINDOW WIPER MOTOR
Color
Harness
17N400
Base Part #
part# N/A
Service Pigtail
See Below
| Pin | Circuit | Gauge | Circuit Function | Qualifier |
| 1 | CBB45 (BK) | 16 | FUSE OUTPUT OR CIRCUIT BREAKER | |
| 2 | CRW05 (BU) | 16 | RELAY - REAR WIPER | |
| 3 | GD150 (BK-WH) | 16 | GROUND - PILLAR D LEFT # 2ND STUD |
| Available Pigtail Kits | |
| Pigtail Kit Part Number WPT-1147 |
Service Part Number: 3U2Z-14S411-BHAB Gauge: 16 Pin material: Silver Cavities: 3 Vehicle Uses Motor - Rear Window Wiper Motor - Seat Recline Refrigerator |
