Connector End View (C929) - INTERIOR/MAP LAMPS ASSEMBLY, FRONT
WARNING: This page is about a different car, the 2018 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.
Connector: C929
Description
INTERIOR/MAP LAMPS ASSEMBLY, FRONT
Color
GY
Harness
14335
Base Part #
14A464
Service Pigtail
See Below
| Pin | Circuit | Gauge | Circuit Function | Qualifier |
| 1 | CBP60 (YE-VT) | 20 | FUSE CIRCUIT BREAKER | |
| 2 | * | * | Not Used | |
| 3 | VLN33 (GY-VT) | 20 | LAMP - DOME FRONT # DIM REAR | without ambient lighting |
| 3 | VLN33 (GY-VT) | 22 | LAMP - DOME FRONT # DIM REAR | |
| 4 | VLN04 (VT-GY) | 22 | LAMP - DOME FRONT # DIM REAR | |
| 5 | VLN40 (YE-BU) | 20 | LAMP - DOME FRONT # DIM REAR | |
| 6 | GD138 (BK-WH) | 20 | GROUND - COWL SIDE/PILLAR A RIGHT |
| Available Pigtail Kits | |
| Pigtail Kit Part Number WPT-923 |
Service Part Number: 8U2Z-14S411-XA Gauge: 18 Pin material: Silver Cavities: 6 Vehicle Uses Module - Adjustable Pedal Memory Module - Driver Door Radio Switch - Traction Control |
