Connector End View (C412) - PARK/STOP/TURN LAMP, LEFT REAR

WARNING: This page is about a different car, the 2018 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.

Connector: C412

Description

PARK/STOP/TURN LAMP, LEFT REAR

Color

Harness

14014

Base Part #

part# N/A

Service Pigtail

See Below

Courtesy of FORD MOTOR COMPANY

Pin	Circuit	Gauge	Circuit Function	Qualifier
1	CLS44 (VT-BN)	18	CTRL MOD. - STOP LEFT REAR
2	CLS45 (VT-GN)	22	CTRL MOD. - PARK LAMP LEFT REAR
3	CLS23 (GY-OG)	18	CTRL MOD. - TURN LAMP LEFT REAR	without door modules
3	CLS27 (GN-OG)	18	CTRL MOD. - TURN LAMP LEFT REAR	with door modules
4	GD150 (BK-WH)	16	GROUND - PILLAR D LEFT # 2ND STUD

Available Pigtail Kits

Pigtail Kit Part Number

WPT-1076

Courtesy of FORD MOTOR COMPANY

Service Part Number:

3U2Z-14S411-BUB

Gauge:

Pin material:

Tin (greased)

Cavities:

Vehicle Uses

Connector - Inline

Element - Heated Seat

Lamp - Ash Tray

Lamp - Courtesy - Footwell

Module - Remote Keyless Entry

Motor - Heater/AC Blower (Auxiliary)

Radio - Amplifier

Switch - Convertable Top
