Liftgate Hinge: Removal

WARNING: This page is about a different car, the 2018 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the liftgate. Refer to: Liftgate  .
  2. Remove the liftgate hinge-to-body nuts and remove the hinge.

    Torque

    : 22 lb.ft (30 Nm)

GFD269961Courtesy of FORD MOTOR COMPANY
