System Diagram

WARNING: This page is about a different car, the 2018 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.
GFD269841Courtesy of FORD MOTOR COMPANY
Item Description
1 PATS Antennas
2 RFA Module
3 RF Receiver
4 Ignition Switch
5 Passive Key
6 PCM
7 PATS Enable
8 BCM
