Front Brake Disc Shield: Removal
WARNING: This page is about a different car, the 2018 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Removal steps in this procedure may contain installation details.
NOTE:
10.94in (278mm) brakes shown, 12.60in (320mm) brakes similar.
- Remove the brake disc. Refer to: Brake Disc .
- Remove the bolts and brake disc.
Torque
: 22 lb.ft (30 Nm)
