Brake Drum: Removal

WARNING: This page is about a different car, the 2018 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.
  1. Refer to: Health and Safety Precautions .
  2. Remove the wheel and tire. Refer to: WHEEL AND TIRE .
  3. NOTE: Use of a brake drum puller or a torch is not recommended. Brake drum distortion can result.
    NOTE: If the brake drum is seized to the wheel hub pilot diameter, tap the center of the brake drum between the wheel studs.

    Remove the brake disc.

GFD264489Courtesy of FORD MOTOR COMPANY
