Section 1470 (OEM Wiring Diagrams (Except Electric))
>>
Adjustable Steering Column
Adjustable Steering Column
WARNING:
This page is about a different car, the 2018 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Adjustable Steering Column System Wiring Diagram
Courtesy of FORD MOTOR COMPANY
