Section 27 (OEM Wiring Diagrams (Except Hybrid))
>>
Parking Rear and License Lamps
>>
Notes
Parking Rear and License Lamps: Notes
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Parking Rear And License Lamps Wiring Diagram
Courtesy of FORD MOTOR CO.
