Section 27 (OEM Wiring Diagrams (Except Hybrid))
>>
Cruise Control
>>
2.5L, 3.0L
2.5L, 3.0L
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Cruise Control Wiring Diagram - 2.5L, 3.0L
Courtesy of FORD MOTOR CO.
