Output Shaft Seal and Flange: Notes

WARNING: This page is about a different variant/trim than selected.
Fig 1: Exploded View Of Output Shaft Seal And Flange
G07402207Courtesy of FORD MOTOR CO.
Item Description
1 Collapsible spacer (part of 7275 kit)
2 Output shaft seal (part of 7275 kit)
3 Output pinion flange (part of 7275 kit)
4 Pinion flange nut (part of 7275 kit)
