Valve Spring, Retainer, and Seal: Installation

WARNING: This page is about a different car, the 2012 Ford Fusion. However, it is still accessible from the selected car via links, so may be relevant.
    NOTE: Lubricate the valve guide with clean engine oil.
    Fig 1: Installing Valve Seal Using Valve Stem Oil Seal Installer
    G06095599Courtesy of FORD MOTOR CO.
  1. Using the Valve Stem Oil Seal Installer, install the new valve seal.
    2. NOTE: If the components are to be reinstalled, they must be installed in their original positions or damage to the engine may occur.
    Fig 2: Removing/Installing Valve Spring, Retainer And Key
    G06095597Courtesy of FORD MOTOR CO.
  2. Using the Valve Spring Compressor, install the valve spring, retainer and key.
  3. Install the camshaft roller followers. For additional information, refer to CAMSHAFT ROLLER FOLLOWER .
