Valve Cover - RH (View 1 of 4)
Fig 1: Valve Cover Replacement Components With Torque Specifications And Tightening Sequence -- RH (View 1 Of 4)
ITEM DESCRIPTION
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | LH turbocharger bypass valve electrical connector (part of 12C508) |
| 2 | 9J478 | LH turbocharger bypass valve hose |
| 3 | - | Turbocharger wastegate regulating valve hose |
| 4 | 14A464 | RH turbocharger bypass valve electrical connector (part of 12C508) |
| 5 | 9J478 | RH turbocharger bypass valve hose |
| 6 | W713946 | RH Charge Air Cooler (CAC) tube nut |
| 7 | 6C646 | RH CAC tube |
| 8 | 6C646 | RH CAC tube |
| 9 | 9C490 | Brake booster vacuum hose retainers |
