Valve Cover - LH (View 1 of 4)

Fig 1: Identifying Valve Cover Components - LH (View 1 Of 4)
G07815183Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION

Item Part Number Description
1 - Turbocharger Boost Pressure (TCBP)/Charge Air Cooler Temperature (CACT) Sensor electrical connector (part of 12C508)
2 6F073 Charge Air Cooler (CAC) outlet pipe
3 - LH Variable Camshaft Timing (VCT) solenoid electrical connector (part of 12C508)
