Valve Cover - LH: Notes

WARNING: This page is about a different car, the 2005 Ford Pickup and 2005 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
MATERIAL

Item Specification
SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP or equivalent WSS-M2C930-A
Metal Surface Prep ZC-31 -
Silicone Gasket Remover ZC-30 -
Silicone Gasket and Sealant TA-30 or equivalent WSE-M4G323-A4
Fig 1: Exploded View Of Valve Cover - RH (1 Of 2)
G03919868Courtesy of FORD MOTOR CO.
Fig 2: Exploded View Of Valve Cover - RH (2 Of 2)
G03919869Courtesy of FORD MOTOR CO.
