Rotor Splash Shield
To remove splash shield, caliper and hub and rotor assemblies must be removed (not necessary to disconnect hydraulic lines). Remove three splash shield bolts. Remove shield and gasket. To install, reverse removal procedure (straighten shield if bent).
