Caution / Notice / Hint

COMPONENTS (REMOVAL)

Fig 1: Power Back Door Control Switch Removal Components
GTY1228689Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Procedure Part Name Code
1 NO. 1 INSTRUMENT PANEL REGISTER ASSEMBLY 55650 See step  1 - -
2 INTEGRATION CONTROL AND PANEL ASSEMBLY 84010D - - -
