Caution / Notice / Hint

COMPONENTS (REASSEMBLY)

Fig 1: Rear Spoiler Reassembly Components

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Procedure		Part Name Code
1	PROTECTOR	-	See step 1	-	-
2	NO. 2 REAR SPOILER PROTECTOR	76873	See step 2	-	-
3	NO. 1 REAR SPOILER PROTECTOR	76872	See step 3	-	-
4	CENTER STOP LIGHT CORD ASSEMBLY	81935D	-	-	-
5	CENTER STOP LIGHT ASSEMBLY	81570	-	-	-

•

Non-reusable part
