Installation [09/2023 - ]: Procedure

INSTALL METER MIRROR SUB-ASSEMBLY
1. Fig 1: Meter Mirror Sub-Assembly Tightening Sequence
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  1. Engage the guide and clip.
  2. Install the meter mirror sub-assembly with the 3 bolts in the order shown in the illustration.
    Torque: 12.5 N.m (127 kgf/cm, 9 ft.lbf)
  3. Connect the 2 connectors.
INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY
Refer to INSTALLATION [09/2023 - ]
