Caution / Notice / Hint
WARNING: This page is about a different car, the 2025 Lexus NX 350h, 2024 Lexus NX 350h, 2023 Lexus NX 350h, and 2022 Lexus NX 350h. However, it is still accessible from the selected car via links, so may be relevant.
The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are removed and installed, or replaced during inverter water pump assembly removal/installation are shown below.
NECESSARY PROCEDURES AFTER PARTS REMOVED/INSTALLED/REPLACED
| Replaced Part or Performed Procedure |
Necessary Procedures |
Effect/Inoperative Function When Necessary Procedures are not Performed |
Link |
| Front bumper assembly*1 |
Front television camera view adjustment |
Panoramic View Monitor System |
Refer to CALIBRATION [11/2021 - 03/2024] |
| Advanced Park |
Refer to CALIBRATION [11/2021 - 03/2024] |
Replacement or removal and installation of 2 or more parts:
- Front television camera assembly, Radiator grille sub-assembly or Front bumper assembly
- Rear television camera assembly
- Side television camera assembly LH, Parking assist light LH or Outer rear view mirror assembly LH
- Side television camera assembly RH, Parking assist light RH or Outer rear view mirror assembly RH
|
Television camera view adjustment |
Panoramic View Monitor System |
Refer to CALIBRATION [11/2021 - 03/2024] |
| Front side radar sensor |
Adjust front side radar sensor |
- Front Camera System
- Front Side Radar Sensor System
|
Refer to ADJUSTMENT [11/2021 - ] |
| Headlight ECU sub-assembly LH |
- Synchronize vehicle information
- Perform headlight ECU sub-assembly LH initialization
|
Lighting system (w/ Automatic Headlight Beam Level Control System) |
Refer to INITIALIZATION [11/2021 - 03/2022]
, or refer to INITIALIZATION [03/2022 - ] |
*1: Even when not replacing the part, it is necessary to perform the specified necessary procedures after installation.
