Caution / Notice / Hint

COMPONENTS (REMOVAL)

Fig 1: Reserve Lock Switch Removal Components
GTY1214909Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Procedure Part Name Code
1 BACK DOOR INSIDE HANDLE 69212C See step  1 - -
2 BACK DOOR CONTROL SWITCH 84931C - - -
