Caution / Notice / Hint

COMPONENTS (REMOVAL)

Fig 1: Back Door Opener Switch Removal Components
GTY1135752Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Procedure Part Name Code
1 REAR LIGHT ASSEMBLY - See step  1 - -
2 BACK DOOR OPENER SWITCH ASSEMBLY 84840G - - -
