Removal [11/2021 - ]: Procedure

  1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY

    Refer to REMOVAL [11/2021 - ]

  2. REMOVE METER MIRROR SUB-ASSEMBLY
    1. GTY1068883Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
