Components [03/2017 - 05/2023]

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2024 Lexus LC 500, 2023 Lexus LC 500, 2022 Lexus LC 500, 2021 Lexus LC 500, and 2020 Lexus LC 500. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Active Rear Wing Switch Replacement Components [03/2017 - 05/2023]
GTY797238Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 NO. 4 COMBINATION SWITCH ASSEMBLY *2 RADIO REMOTE TUNING SWITCH ASSEMBLY
*3 REAR CONSOLE BOX POCKET *4 SHIFTING HOLE COVER ASSEMBLY
