Removal [06/2018 - ]: Procedure

  1. REMOVE RADIO RECEIVER ASSEMBLY WITH SWITCH

    Refer to REMOVAL [06/2018 - 08/2020] , or refer to REMOVAL [08/2020 - 09/2022] , or refer to REMOVAL [09/2022 - ]

  2. REMOVE REFRESHING SEAT SWITCH
    1. Remove the 2 screws.
      GTY786963Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    2. Disengage the 4 guides to remove the refreshing seat switch.
