Installation [10/2018 - ]: Procedure

1. Engage the clip as shown in the illustration.
   Fig 1: Meter Mirror Sub-Assembly Nut Tightening Sequence

   Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

   Install in this Direction

2. Temporarily install the meter mirror sub-assembly with the 3 nuts.
3. Tighten the 3 nuts in the order shown in the illustration.

   Torque: 10 N.m (102 kgf/cm, 7 ft.lbf)

4. Connect the connector.

Refer to INSTALLATION [10/2018 - 08/2021] , or refer to INSTALLATION [08/2021 - 07/2022] , or refer to INSTALLATION [07/2022 - ]
