Removal [12/2021 - ]: Procedure

  1. REMOVE FRONT FENDER MUDGUARD LH
    1. GTY1081617Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      Remove in this Direction (1) Remove in this Direction (2)
      Screw - -
      1. Using a 4 mm hexagon socket wrench, remove the 4 screws.
      2. Detach the guide and remove the front fender mudguard LH as shown in the illustration.
