Components [11/2021 - ]

Fig 1: Performance Damper Replacement Components With Torque Specifications
GTY1083147Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 REAR BUMPER ASSEMBLY *2 SUSPENSION TOWER DAMPER
*3 REAR COMBINATION LIGHT COVER LH *4 REAR COMBINATION LIGHT COVER RH
N.m (kgf/cm, ft.lbf): Specified torque * For use with SST
