Removal [09/2020 - ]: Procedure

  1. REMOVE COOL AIR INTAKE DUCT SEAL

    Refer to PROCEDURE - Step 1

  2. REMOVE FRONT TELEVISION CAMERA ASSEMBLY
    1. Remove the 2 screws.
      GTY970640Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    2. Disengage the 2 guides.
    3. Disconnect the connector to remove the front television camera assembly.
